320w Electric Germicidal UV Lamp Ballast With Indicator Function

Ningbo Uv Light & Electricity Co., Ltd.
Contact Now
    Buy cheap 320w Electric Germicidal UV Lamp Ballast With Indicator Function from wholesalers

    Buy cheap 320w Electric Germicidal UV Lamp Ballast With Indicator Function from wholesalers
    • Buy cheap 320w Electric Germicidal UV Lamp Ballast With Indicator Function from wholesalers
    • Buy cheap 320w Electric Germicidal UV Lamp Ballast With Indicator Function from wholesalers

    320w Electric Germicidal UV Lamp Ballast With Indicator Function

    Ask Lasest Price
    Brand Name : UV
    Model Number : PH7-800-2/155UV
    Certification : CE,ROHS
    Price : 100
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 10000 pcs per month
    Delivery Time : 3 days
    • Product Details
    • Company Profile

    320w Electric Germicidal UV Lamp Ballast With Indicator Function

    Electric ballasts 320w With Indicator Function For Two Pcs 90w-155w UVC Lamps

    The basic composition of the ultraviolet sterilizer is the ultraviolet germicidal lamp tube and the power distribution system. The most important part of the power distribution system is the ballast. Therefore, it can be said that the ultraviolet sterilizer is composed of ultraviolet germicidal lamps and ballasts.
    Ultraviolet sterilizer manufacturers have found through experiments that when the same ultraviolet germicidal lamp is replaced with an electronic ballast, the power consumption can be reduced by more than 25%, while the radiation intensity can be increased by more than 12%, and the lamp life is greatly extended. Especially for some ultraviolet germicidal lamps that use inductive ballasts and the radiation intensity does not meet the disinfection requirements, as long as the radiation intensity is above 60μW/cm2, when switching to electronic ballasts, the requirements can be basically met.
    PH8 series 55W-155W
    ■Features
    • Preheat start.
    • With indicator function. Green led indicates UV lamp
    operating normally. Red led indicates UV lamp broken down,
    with functions of on-off value (dry contacts).
    • Double lamp parallel structure design, two groups of UV
    lamp state feedback function
    ■Load Lamp
    • PH8-1200-2/105U:
    2*GPHVA843T5,GPHVA357T5
    Wiring diagram: A
    • PH8-800-2/155:
    2*GPH1554T5HO,GHO64T5,TUV64T5HO,TUVPL-L95WHO,TL100W
    Wiring diagram: A
    • PH8-800-2/87U:
    2*GPH893T5HO,GPH846T5HO,GHO36T5,TUV95WHOPL-L,TUV75WHO,
    TUV60WHO,TUV55WHO,TUV36T5HO
    Wiring diagram: A
    • PH8-425-2/75U:
    2*GPH1554T5L,GPH1630T5L,GPH843T5L
    Wiring diagram: A
    ■Packaging information
    • Size of Ballast: 250*65*40mm
    Mounting Distance:240mm
    • Size of Package: 460*270*190mm
    Quantity:18PCS
    Note for ordering
    ・ Input power cord should be changed into different national
    standardized power cord. Such as GB, BIS, CE, SAA, etc.
    Different power cord has different ordering number (must
    check it carefully before ordering). Output line can also be
    changed into 4*0.5 mm2,4*18#,5*18#, etc. Output line can
    add waterproof connector, dust cover, hole plugs, detailed
    information see the accessories list.
    The power supply must be cut off before installing and
    replacing the ballast.The connecting line between ballast
    and lamp tube shall not exceed 5m
    Product Description

    Product name
    Electronic ballast for 90-155w uv lamps
    Input Wattage
    320w
    Voltage
    220 v -240v
    Lamp quantity
    2 pcs
    Color
    White
    Application
    Germicidal ultraviolet Lamps
    Size
    25*6.5*4 cm
    Brand
    UV or OEM
    Warranty
    2 years


    Product Presentation

    Ballasts can be complicated. Nobody replaces ballasts regularly. Inevitably, ballasts are needed when you go to change out the UV bulb at your machine's recommended intervals when you realize that the new bulb is not lighting up or is flickering. Instead of an easy UV bulb switch, your maintenance just became a potentially complicated electronic ballast search and installation.
    Finding the right ballast is the first hurdle but not the only one. Even after you take receipt of the ballast, you have to figure
    out how to wire them. Depending on the bulb type and the number of bulbs in your system, the wiring can change completely. It is not incredibly complicated, but more troublesome than it is worth for the majority of UV air or water purification system operators.
    we want to take the guesswork out of ballast replacement. With this ballast, you are guaranteed to receive the right
    ballast with the right wiring diagram. Any questions, and we'll be here every step along the way to help you out.


    Product Name
    Electronic ballast
    Material
    Iron
    Inpurt Power
    320w
    Voltage
    220
    Type of Lamp-house
    all
    Model
    PH8-800-2-155
    Style
    Electric
    We design and manufacture UVC ballasts for a wide range of germicidal ultraviolet lamps used in a variety of water, air, and surface purification devices. Our ballasts are essential to increasing the safety and working lifetime of UVC lamps. No matter the size, power, or lamp configuration required for your application, Our team of engineers will design and manufacture a ballast with the desired certifications to fit perfectly into your system. Our collaborative approach helps us serve as an extension of your engineering and design team.
    Company Introduction
    FAQ
    FAQ Q1: What is your main product? A: We focus on UV light lamp, UV sterilizer and related product. Q2: Are you a Manufacturer and Trading Company? A:We are a manufacturer of UV sterilizer and UV germicidal lamp with over 20 years' experiences in industy. We are able to provide you a perfect solution for your inquiry. Q3: What is the minimum order quantity? A: Our MOQ is 100pcs. Q4:Can i get sample for testing? A:Yes. Testing samples are charged. You only need to pay for the shipping. Q5: Can i print logo on led light product? A: Certainly. Please provide your logo design for checking. Q6: What kind of shipping do you use to ship the products? A: For small quantity order we ship by courier, this is the most reliable service in order to reach you promptly and safely. For big quantity order,we ship by sea or by air. Q7: What is your payment? A: Cash, T/T, L/C, Credit Card, Paypal etc.
